关键信息提取(KIE)

环境准备

服务器

· OS: CentOS7.9

· GPU: RTX3090 24G2

· CUDA: 11.7

· CUDNN: 8.9.2

### 飞桨

· paddlepaddle: paddlepaddle-gpu==2.4.2(cudatoolkit=11.7,建议conda安装)

1
conda install paddlepaddle-gpu==2.4.2 cudatoolkit=11.7 -c https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud/Paddle/ -c conda-forge


· paddleocr: 2.9.1

· paddlenlp: 2.5.2

### 项目依赖包

requirements.txt

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
# paddlepaddle 2.4.2 注:必须
# conda install paddlepaddle-gpu==2.4.2 cudatoolkit=11.7 -c https://mirrors.tuna.tsinghua.edu.cn/anaconda/cloud/Paddle/ -c conda-forge

shapely
scikit-image
pyclipper
lmdb
tqdm
numpy
rapidfuzz
opencv-python
opencv-contrib-python
cython
Pillow
pyyaml
requests
albumentations==1.4.10
# to be compatible with albumentations
albucore==0.0.13

sentencepiece
yacs
seqeval
pypandoc
attrdict3
python_docx
paddlenlp==2.5.2


注: bugfix

1. `ModuleNotFoundError: No module named ‘ppocr.**
前往官方github主页(<https://github.com/PaddlePaddle/PaddleOCR>)补齐源码到python环境 e.g.conda 虚拟环境下,需要补齐的源码根目录为:/root/anaconda3/envs/py39_kie/lib/python3.9/site-packages/paddleocr/ppocr<font color='gold'>**2.**</font>ModuleNotFoundError: No module named ‘paddle.fluid’安装较低版本paddlepaddlepaddle2.4.2/2.5.0<font color='gold'>**3.**</font> 类型错误:
1
2
3
InvalidArgumentError: The type of data we are trying to retrieve does not match the type of data currently contained in the container.
[Hint: Expected dtype() == paddle::experimental::CppTypeToDataType<T>::Type(), but received dtype():10 != paddle::experimental::CppTypeToDataType<T>::Type():9.] (at /paddle/paddle/phi/core/dense_tensor.cc:143)
[operator < less_equal > error]
官方示例bug,需要添加参数项
–use_visual_backbone = False<!--more--> ## 模型 参考:<https://paddlepaddle.github.io/PaddleOCR/latest/ppstructure/model_train/train_kie.html> ### 准备(inference模型) SER任务模型下载链接:<https://paddleocr.bj.bcebos.com/ppstructure/models/vi_layoutxlm/ser_vi_layoutxlm_xfund_infer.tar> RE任务模型下载链接:<https://paddleocr.bj.bcebos.com/ppstructure/models/vi_layoutxlm/re_vi_layoutxlm_xfund_infer.tar> 创建项目根目录demo并添加测试图片1.png,在demo目录下新建models文件夹用于存放OCR、SER、RE模型、字典文件、字体文件。其中OCR模型可使用ppocrv3、v4版本下检测和识别(det/rec)模型,字典文件复制源码目录下paddleocr/ppocr/utils/dict/kie_dict/xfund_class_list.txt,字体文件使用simfang.ttf### SER/RE模型串联 <font color='gold'>**1.**</font>创建官方代码示例demo/test.py用于测试和显示图像(源码:paddleocr/ppstructure/kie/predict_kie_token_ser_re.py
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
# Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
import os
import sys

__dir__ = os.path.dirname(os.path.abspath(__file__))
sys.path.append(__dir__)
sys.path.insert(0, os.path.abspath(os.path.join(__dir__, "../..")))

os.environ["FLAGS_allocator_strategy"] = "auto_growth"

import cv2
import json
import numpy as np
import time

import paddleocr.tools.infer.utility as utility
from paddleocr.tools.infer_kie_token_ser_re import make_input
from paddleocr.ppocr.postprocess import build_post_process
from paddleocr.ppocr.utils.logging import get_logger
from paddleocr.ppocr.utils.visual import draw_ser_results, draw_re_results
from paddleocr.ppocr.utils.utility import get_image_file_list, check_and_read
from paddleocr.ppstructure.utility import parse_args
from paddleocr.ppstructure.kie.predict_kie_token_ser import SerPredictor

logger = get_logger()


class SerRePredictor(object):
def __init__(self, args):
self.use_visual_backbone = args.use_visual_backbone
self.ser_engine = SerPredictor(args)
if args.re_model_dir is not None:
postprocess_params = {"name": "VQAReTokenLayoutLMPostProcess"}
self.postprocess_op = build_post_process(postprocess_params)
(
self.predictor,
self.input_tensor,
self.output_tensors,
self.config,
) = utility.create_predictor(args, "re", logger)
else:
self.predictor = None

def __call__(self, img):
starttime = time.time()
ser_results, ser_inputs, ser_elapse = self.ser_engine(img)
if self.predictor is None:
return ser_results, ser_elapse

re_input, entity_idx_dict_batch = make_input(ser_inputs, ser_results)
if self.use_visual_backbone == False:
re_input.pop(4)
for idx in range(len(self.input_tensor)):
self.input_tensor[idx].copy_from_cpu(re_input[idx])

self.predictor.run()
outputs = []
for output_tensor in self.output_tensors:
output = output_tensor.copy_to_cpu()
outputs.append(output)
preds = dict(
loss=outputs[1],
pred_relations=outputs[2],
hidden_states=outputs[0],
)

post_result = self.postprocess_op(
preds, ser_results=ser_results, entity_idx_dict_batch=entity_idx_dict_batch
)

elapse = time.time() - starttime
return post_result, elapse


def main(args):
image_file_list = get_image_file_list(args.image_dir)
ser_re_predictor = SerRePredictor(args)
count = 0
total_time = 0

os.makedirs(args.output, exist_ok=True)
with open(
os.path.join(args.output, "infer.txt"), mode="w", encoding="utf-8"
) as f_w:
for image_file in image_file_list:
img, flag, _ = check_and_read(image_file)
if not flag:
img = cv2.imread(image_file)
img = img[:, :, ::-1]
if img is None:
logger.info("error in loading image:{}".format(image_file))
continue
re_res, elapse = ser_re_predictor(img)
re_res = re_res[0]

res_str = "{}\t{}\n".format(
image_file,
json.dumps(
{
"ocr_info": re_res,
},
ensure_ascii=False,
),
)
f_w.write(res_str)
if ser_re_predictor.predictor is not None:
img_res = draw_re_results(
image_file, re_res, font_path=args.vis_font_path
)
img_save_path = os.path.join(
args.output,
os.path.splitext(os.path.basename(image_file))[0] + "_ser_re.jpg",
)
else:
img_res = draw_ser_results(
image_file, re_res, font_path=args.vis_font_path
)
img_save_path = os.path.join(
args.output,
os.path.splitext(os.path.basename(image_file))[0] + "_ser.jpg",
)

cv2.imwrite(img_save_path, img_res)
logger.info("save vis result to {}".format(img_save_path))
if count > 0:
total_time += elapse
count += 1
logger.info("Predict time of {}: {}".format(image_file, elapse))


if __name__ == "__main__":
args = parse_args()
args.mode = 'kie'
args.use_visual_backbone = False
args.kie_algorithm = 'LayoutXLM'
args.re_model_dir = './models/re_vi_layoutxlm_xfund_infer'
args.ser_model_dir = './models/ser_vi_layoutxlm_xfund_infer'
args.ser_dict_path = './models/xfund_class_list.txt'
args.vis_font_path = './models/simfang.ttf'
args.ocr_order_method = "tb-yx"
args.det_model_dir = './models/ch_PP-OCRv3_det_infer'
args.rec_model_dir = './models/ch_PP-OCRv4_rec_infer'
args.image_dir = './1.png'
main(args)
![](关键信息提取(KIE)\1.png) <font color='gold'>**2.**</font>创建
demo/main.py用于测试
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
import cv2
import time
from paddleocr.ppstructure.kie.predict_kie_token_ser_re import SerRePredictor
from paddleocr.ppstructure.utility import parse_args
from paddleocr.tools.infer_kie_token_ser_re import make_input


# 继承SerRePredictor类,重写__call__方法,实现同时输出Ser模型结果
class KIE(SerRePredictor):
def __init__(self, para):
super().__init__(para)

def __call__(self, im):
start_time = time.time()
ser_results, ser_inputs, ser_elapse = self.ser_engine(im)
if self.predictor is None:
return ser_results, ser_elapse

re_input, entity_idx_dict_batch = make_input(ser_inputs, ser_results)
if not self.use_visual_backbone:
re_input.pop(4)
for idx in range(len(self.input_tensor)):
self.input_tensor[idx].copy_from_cpu(re_input[idx])

self.predictor.run()
outputs = []
for output_tensor in self.output_tensors:
output = output_tensor.copy_to_cpu()
outputs.append(output)
preds = dict(
loss=outputs[1],
pred_relations=outputs[2],
hidden_states=outputs[0],
)

post_result = self.postprocess_op(
preds, ser_results=ser_results, entity_idx_dict_batch=entity_idx_dict_batch
)

elapse_time = time.time() - start_time
return ser_results, post_result, elapse_time


if __name__ == "__main__":
args = parse_args()
args.mode = 'kie'
args.show_log = True
args.use_visual_backbone = False
args.kie_algorithm = 'LayoutXLM'
args.re_model_dir = './models/re_vi_layoutxlm_xfund_infer'
args.ser_model_dir = './models/ser_vi_layoutxlm_xfund_infer'
args.ser_dict_path = './models/xfund_class_list.txt'
args.vis_font_path = './models/simfang.ttf'
args.ocr_order_method = "tb-yx"
args.det_model_dir = './models/ch_PP-OCRv3_det_infer'
args.rec_model_dir = './models/ch_PP-OCRv4_rec_infer'
args.det_limit_side_len = 1600,

kie = KIE(args)
img = cv2.imread('./1.png')
ser_res, re_res, elapse = kie(img)
print(ser_res, '\n', re_res, '\n', elapse)
